AEM 22 Channel CAN Expander Module - 30-2212

AEM ElectronicsSKU: AEM30-2212

Price:
$449.95 $506.95
Stock:
Available (14 units), to ship. For local pickup, please contact us.

Description

AEM 22-channel CAN sensor modules provide a way for users with carbureted vehicles to add an AEM CD digital dash display. They also let users with existing CAN-based devices add more channels to the display for viewing and/or data logging. These 22-channel modules convert analog, digital, and frequency inputs into an AEMnet CAN bus signal that can be transmitted to AEM's CD-5 carbon and CD-7 digital dashes.

AEM Electronics 22-channel CAN sensor module includes:

  • Wiring harness with 36 in. flying leads and pre-wired CAN cable
  • IP65-rated enclosure is dust-tight and water-resistant
  • Daisy-chain two modules together for additional channels (modules sold individually)
  • Four dedicated 0-5 V analog inputs
  • Four temperature (thermistor) inputs
  • Four user-configurable inputs for 0-5 V, temp (including RTD)
  • One dedicated fuel level input (0 to 250 ohm range)
  • Six digital inputs, active low, protected to about 18 V, frequency, duty cycle or simple switch
  • One tach input, trigger when low, 12 V internal pull up
  • Two VR pair frequency inputs (crank, wheel, or driveshaft speeds)
  • Jumper selectable CAN bus speeds, 250k, 500k, 1M
  • Jumper selectable terminating resistor
  • Jumper selectable header length, 11 bit or 29 bit
