Radium Engineering Universal Check Valve - 20-0534

Radium EngineeringSKU: RAD20-0534

Price:
$47.45 $49.95
Stock:
Available (7 units), to ship. For local pickup, please contact us.

Description

20-0534 UNIVERSAL CHECK VALVE

The internal plunger's aerodynamic shape warrants a smooth laminar stream. All female AN ports can accept 37 degree flare male fittings and/or ORB (O-ring boss) male fittings. The flow direction is laser etched on the side of the part. In it's native form without adapter fittings, the universal check valve uses a 10AN male outlet and a 8AN female inlet.


SPECS & FEATURES

20-0534 and 20-0534-XX Check Valves

  • Body Seal: FKM
  • Plunger Seal: FKM
  • Hardware: Stainless Steel
  • Spring Material: Stainless Steel
  • Plunger Material: Stainless Steel
  • Body Material: Anodized Aluminum
  • Check Valve Type: Spring-Loaded Piston
  • Large Hex: 30mm (or 1-3/16")
  • Length, No Adapters: 1.72" (43.6mm)
  • Cracking Pressure: 0.3 psi @ 70F
  • Max Operating Pressure: 1000+psi @ 70F
  • Backflow Holding Pressure: 1000+psi @ 70F
